AED Storage Software (Option)
Its used to assist upper supervisory system of Automatic External Defibrillator DEFI and support transmission of storage data from lower control system of DEFI. It is used for event documentation, display of real-time ECG, voice prompts waveform, display of voice prompts and print of selected waveforms.
Type: | Automatic External Defibrillator |
Self-test: | Daily, Weekly, Monthly |
Mode: | Adult |
Waveform: | Biphasic truncated exponential |
Energy: | 200-Joules max. |
Energy Sequence: | 150, 150, 200-Joule |
Charge time: (New, at 25℃) |
Less than 6 sec. to 150J Less than 8 sec. to 200J |
Voice Prompt: | Extensive voice prompt |
Visual Indicators: | LED prompts |
Control: | Two buttons: ON/OFF, Shock |
ECG storage: | 1500 events. |
Data transmission | Infrared |
Battery | |
Power: | 12V, 3000mAh |
Type: | Non-rechargeable |
Li-MnO2 Cell | |
Environmental | |
Operating Temperature |
0℃ to 40℃ |
Operating Humidity |
Relative humidity between 30% and 95% (non-condensing) |
Storage Temperature (without battery) |
-20℃ to 55℃ |
Storage Humidity (without battery) |
Up to 93% (non-condensing) |
Physical | |
Dimensions |
Depth:256mm, Width: 220mm Height:(L:65mm, H:80mm) |
Weight (with battery): |
1.9Kg (4.2 Pounds) |
AED Pad .................... 1Pcs
Battery ...........................1Pcs
AED Case ...................... 1Pcs
Cleaning Cloth ................1Pcs
Options:
AED Cabinet
IrDA USB Adapter for ECG Data transfer
CD Software for ECG Data transferRelated items
